Engineering Design Division
The division mainly handles the design of engineering parts , components and machinery design of various structures from auto/automobile segment , heavy engineering components and machine tool segment etc.,
The preliminary design is made with CAD/CAM and the CAD module is analysed through numerical computational simulation for the design andvit is mainly performed in CAE Software, like ANSYS Work-bench etc.,
The final design is checked with numerous loads cases for structural strength , stiffness , durability- fatigue failure etc.,
Classifications in Engineering Design solutions
- New Part/Component design for mechanical / thermal loads
- Re-Engineering design for mechanical / thermal loads
- Failure Analysis of the component due to mechanical loads
- Structural analysis of any steel structure under dead , wind, seismic loads
A case study of bracket design of the engineering component , under the given load the bracket tends to be safe , but in the running condition the part is generating a crack and fails within its yield strength.
Engineering solution :
The bracket is a engineering part in which the components are mounted to with-stand the presumptive static-loads.
